Dimension

Wingspan：620 mm

Dimensions(Unfolded)：620*503 mm

Dimensions(Folded)：100*503 mm

Weight

Max. Payload：1.2 kg

Max. Takeoff Weight：2.7 kg

Comm. & Nav

Transmission Range：20 km

GNSS：GPS+GLONASS+BeiDou+Galileo

Performance

Max. Flight Time：30 min

Cruising Speed：30 km/h

Max. Horizontal Speed：12 m/s

Max. Ascent Speed：5 m/s

Max. Descent Speed：3 m/s

Max. Flight Distance：20 km

Max. Flight Altitude：3000 m

Environment

Max. Wind Resistance：Level 6

IP Protection Rating：IP54

Operating Temperature：-20~60℃

Aircraft Parameters

Camera Parameters

Gimbal

Stabilized System：2-axis

Mechanical Range：Roll: -100~100°；Pitch: -100~10°

General

Weight：51 g

Dimensions：57.5*49*47.1 mm

Voltage：3.5~5.5V

Operating Temperature：-20~60 ℃

Visible Light Camera

Resolution：1080P

Focal length：2.4 mm

Frame rate：25 fps
